• KPS-AS-01
    KPS-AS-01

    KPS-AS-01

    DESCRIPTIONS :

           ◆Contact Rating : 5A With Resistive Load @ 120VAC or 28VDC.
       ◆Electric Life : 60,000 Make-And-Break Cycles at Full Load.
       ◆Contact Resistance : 20m Ohm. max. inital @2.4VDC. 100mA for Both Coin Silver And Gold Plated Contacts.
       ◆Insulation Resistance : 1,000M Ohm. Min
       ◆Dielectric Atrength : 1,000V RMS @Sea Level
       ◆Operating Temperature : -30degree ~ +85degree
