• KPS-A101,KPS-A101L
    KPS-A101,KPS-A101L

    KPS-A101,KPS-A101L

    DESCRIPTIONS :

      ◆Contact Rating : 5A With Resistive Load @ 120VAC or 28VDC.
      ◆Electric Life : 50,000 Make-And-Break Cycles at Full Load.
      ◆Contact Resistance : 10m Ohm. max. inital @2.4VDC.
         100mA for Both Coin Silver And Gold Plated Contacts.
      ◆Insulation Resistance : 1,000M Ohm. Min
      ◆Dielectric Atrength : 1,000V RMS @Sea Level
      ◆Operating Temperature : -30degree ~ +130degree
