• KD-640
    KD-640

    KD-640

    Specifications
      ˙Circuit : A : ON-OFF
                       B : ON-ON
                       L : illuminated
      ˙Rating : 10A 125VAC/250VAC
      ˙Contact Resistance : 30mΩ(max.)
      ˙Insulation Resistance : DC 500V 100MΩ(min.)
      ˙Dielectric Strength : AC 1000V 1 Minute
      ˙Operation Force : 800±300g
      ˙Operation Life : 10000 Cycle at Full Load
      ˙Operation Temperature Range : -25℃~+85℃
      ˙Soldering Heat Temperature : 280℃ 3 Sec
