• KD-606-1 Series
    KD-606-1 Series

    KD-606-1 Series

    Specifications
     ˙Circuit : SPST ON-OFF
     ˙Rating: 6A 125VAC/3A 250VAC
     ˙Contact Resistance : 30mΩ(max.)
     ˙Insulation Resistance : DC 500V 100MΩ(min.)
     ˙Dielectric Strength : AC1000V 1 Minute
     ˙Operation Force : 0.3~0.8Kg
     ˙Operation Life : 10000 Cycle st Full Load
     ˙Operation Temperature Range : ~25 C~+80 C
     ˙Soldering Heat Temperature : 280 C 3 Sec
